Anti Fall Arrester

Anti fall arrester, also called Self-locking Lifelines, is a safety protection product, which using the difference in velocity of an object before and after it unexpectedly falls to perform automatic control.The anti fall arrester can quickly brake and lock the steel cable within a limited distance to prevent falling objects from falling. It’s load capacity is 150-300kg.

Send email to us Download as PDF

Product Detail

Product Tags

product description

The anti-fall arrester is an essential safety device that is widely used in various industries, including power plant, construction site, mining, and shipping. Its main function is to protect workers from falling accidents, ensuring their safety and reducing the risk of workplace injuries. By investing in this device, businesses can ensure the safety of their workers while minimizing the risk of workplace injuries and maximizing the overall efficiency of their operations.

main parameter

Model	TXS150-3	TXS150-5	TXS150-10	TXS150-15	TXS150-20	TXS150-30
Max working load(kg)	150	150	150	150	150	150
Cable material	galvanized steel wire rope
Cover material	aluminum alloy
Cable diameter(mm)	3.2	3.2	3.2	3.2	3.2	3.2
Cable length(m)	5	5	10	15	20	30
Critical speed of locking(m/s)	1
Locking distance	≤0.2m
Overall damage load	≥8900N
Service life(times)	2×10^4

Features

The anti fall arrester has these features as follows:

1. Simple structure, easy to use.
2. Small size, light weight, easy to carry.
3. Various specifications to meet different needs.
4. Economical and practical, long service life
5. Easy to repair and maintain.

product details

Double locking system

Cast steel integrated ratchet

Quenched alloy steel spring

Aluminum alloy integrated cover

Galvanized steel wire rope

200°C high temperature resistant rope

Alloy steel U-shaped lifting ring

Self-locking hook
